Introduction of PCKW Reversible Hammer Crusher:

PCKW reversible hammer crusher integrates the advantages of hammer breaking and counterblow breaking. It is suitable for crushing medium hardness brittle materials with compressive strength less than 150 Mpa, such as coal for coking, anthracite, coal gangue, gypsum, alum and other materials used in sulfide bed boilers of thermal power plants.


Working principle of reversible hammer crusher:

After the material enters the reversible hammer crusher through the feeding hopper, it encounters a high-speed rotating hammer and is hit on the adjustable wear-resistant tooth plate at the crusher's inlet. It is crushed for the first time. After crushing, the material with basically the same particle evenly enters the main crushing chamber for the second main crushing. The homogenized material particles in the main crushing chamber obtain kinetic energy again from the hammer head and rush to the counterattack chamber at high speed. Internal tooth liner, through the upward rebound of the tooth liner, is broken by hammer again, at the same time, the material is also broken by the impact between each other, so repeated cycle, in the counter-attack chamber broken many times, and finally the broken material is discharged from the outlet, the finely broken material is the finished product. Product granularity control is realized by adjusting the clearance between the rotor and the backlash plate.


Performance characteristics of reversible hammer crusher:

The great characteristic of reversible hammer crusher is that the rotor can be reversed. This design can not only realize the perfect operation of wet material, but also improve the utilization ratio of hammer head of crusher. The whole crusher has good performance, large crushing ratio, high productivity and uniform product size.

1. No screen strip, which overcomes the problems of high humidity and easy blockage of materials;

2. The gap between discharge and outlet is adjustable, the grain size of discharge is uniform, the output is large and the energy consumption is low.

3. The rotor can be reversed and reversed to make the hammer head and crushing plate wear uniformly and improve the utilization ratio of the hammer head.

4. The crushing chamber is easy to open and replace the fragile parts. The hydraulic cylinder is used in the large machine.


Product parameters of reversible castor-free hammer crusher:

Note: If the parameters are updated, please contact us without further notice.


PCKW reversible hammer crusher factory picture:

PCKW Reversible Hammer Crusher Video:


Price of PCKW Reversible Hammer Crusher:

The price is determined by the model chosen by the customer, so please call for it.


PCKW Reversible Hammer Crusher Purchasing Advisory Telephone:+86-021-33781259 , Email：info@shhyyj.com
